Tactile & Optical Testing of Electronic Devices

High Repeatability – Force Control – Various Angles

Electronic devices are becoming smaller, more complex, operate in different environments, and include several types of components that require tactile, optical, and electronic testing methods. The position of these devices in the final assembly demands precise positioning of the inspection tool in several degrees of freedom. PI offers powerful flexible motion systems for various test methods that can be integrated into customer production lines while maintaining capacity and throughput.

Tactile and Optical Testing of Electronic Devices — Business Development Manager Rolf Ellerbrock explains the advantages of the motion solution

Unique range of motion technologies to design most advanced solutions

Industrial high-performance motion control platform provides coordinated motion of all axes for maximum throughput

Easy connection and management of third-party sensors and test devices with flexible EtherCAT® connectivity

Can be integrated as a subsystem under most PLCs and automation controllers

Magnetic direct drive linear motors for high precision and high velocity
Absolute encoder with 1nm resolution
XY drag chain cable management
>> V-551 Precision Linear Motor Stage

Ball screw linear motor or voice coil stage
Cable management integration
Holding brake or counterbalance
Direct-measuring linear encoder
>> M-511 High-Precision Linear Stage

Parallel-kinematic hexapod
Six degrees of freedom
Freely definable center of rotation
>> H-811 6-Axis Miniature Hexapod

PIMag® voice coil linear actuator
Force sensor with 1 mN resolution
Weight force compensation
>> V-275 PIMag^® Voice Coil Linear Actuator

ACS SPiiPlus EtherCAT-based motion control platform operates as an independent machine controller or as a subsystem under most PLCs and automation controllers

Motion Controller
>> ACS SPiiPlusES
Universal Servo Drives
>> ACS NPMpm

Solutions for Electronics Manufacturing — The video shows PI solutions for electronics manufacturing

Tactile Testing of Electronic Devices — The video shows a system with a unique range of motion technologies

Electronics Manufacturing: Fingerprint and Pressure Sensor Testing – Camera Lens Alignment – Haptic Tests

Automotive: Testing of Inclination, Velocity and Acceleration Sensors – Lens Alignment – Injection Nozzle Inspection – Haptics Test for Car Keys

Laser Material Processing: Hermetic Seam Welding – Surface Texturing

Semiconductor: X-Ray and Computed Tomography Inspection
